IP54 Single Phase Electric Meter 35mm Din Rail Keypad Prepaid Meter

Micro Grid 35mm Din Rail Keypad Prepaid Meter with RF Communication Remotely Monitoring

The CA168-S is designed as split type, MCU(Main Control Unit) and UIU(User Interface Unit), connected by RF communication. It is suitable for Mini Grid (Micro Grid/Off Grid) solar PV generatation, can be used in 5A, 16A, 40A, 60A current. The meter build in prepayment algorithm which compliance with the STS (Standard Transfer Specification) protocol, the meter will shut off the power automatically when the credit is used up even though there is no any communication between meter and system.

Due to the in-built RF communication in the MCU, the AMR management system can be developed for you to monitoring the meter consumption, collect data from the meter (Credits, consumption, events, etc) and remotely control. The DCU(Data Concentrator Unit) collect the data from the nearby meters by RF, and then upload the data to the system by GPRS.

Major Features

1. 20 digit (Standard Transfer Specification) STS encryption

2. Up to 80A current with Class 1 accuracy

3. Disconnects on overload and no credit

4. Programmable power limit and low credit warning

5. Adjustable power limit trip

6. Enhanced tamper detection for magnetic field, reverse connection, cover open, etc.

7. Reverse energy measurement SRE

8. Information toggled by codes

9. Tamper trip protection : neutral missing

Other Benefits

a) Compact and slim-line design

b) PLC/ RF communication for MCU & UIU and same with back end AMI server (On request)

c) Time of Use (TOU) , multi-rate, tariff control, holiday setting

d) 15 year designed life

e) Enhanced revenue protection through flexible payment control

Specifications:

Calin, as derived from China League of Innovation, dates  back to the year 2006  when our team developed the new generation of CPU card electronic prepaid kilo-watt hour meter for China State Grid. Now there are over 1,000,000 pcs this type of smart prepayment electric meters operating  as key revenue protection devices for utilities and service providers in and out of China.

Each member of Calin R&D team  ever served in top rank Chinese meter companies and contributed to the rapid development of smart metering industry in China. With vast forefront field experience and expertise, Calin offer a broad metering product range, comprising of conventional electric meters, water meters, prepaid meters, wireless communication meters, vending and management systems, AMR / AMI smart metering solutions, consulting, training and support.

Calin is the forerunner of prepaid metering industry in China. Our products and solutions are all developed on the concept of revenue protection and better management, and thus enjoy very high reputation in the industry. Even now China is supplying components, complete products as in OEM, and meter electronic design to many other meter manufacturers. With this OEM and trade partners, Calin’s business has expannded to over 30 countries and regions worldwide.

To share with our clients the benefit from our constant innovation and commit to our clients’ request is Calin’s forever unchanging principle. Running away from responsibility is always condemed. Calin will keep servicing our clients with our best innovation and commitment to create best mutual benefit.
